China suppliers ZING EAR spring slide switch black micro Switch

FOB Reference Price:Get Latest Price
US $0.11-0.25 / Pieces | 500 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
ZING EAR
Model Number:
G10 micro switch, G10
Max. Current:
0.1A 1A 3A
Max. Voltage:
12VDC 36VDC 48VDC 125VAC 250VAC
Operating Temperature:
-25℃~125℃, -25℃~125℃
Protection Level:
IP40
Product Name:
China suppliers ZING EAR spring slide switch black micro Switch
Payment Terms:
T/T,Western Union
Safety approval:
UL, CUL, ENEC, CQC
Terminal Type:
PCB Solder Screw Wire Leads terminals
Operating Force:
50gf 100gf 150gf max.
Lever type:
Long Straight lever, Pin Plunger, Simulated Roller lever
Circuit Code:
SPDT
Electrical life:
25,000,000 cycles Min.
Supply Ability
Supply Ability:
3000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1. Pack out: 1000pcs/ctn.
2. Gloss weight: about 2.7kgs
3. Shipper carton size: 400x305x220mm
Port
Guangzhou, Shenzhen & HK
Lead Time :
2~3 weeks after order received

China suppliers ZING EAR  spring slide switch black micro Switch

Product Description

Feature:

-Tight Configuration,Small Contact Gap , Snap Action

-Long Life, High Reliability

-Global Safety Approvals

-Variety of Terminals

-Wide Range Operating Force

-Wide Range Temperature Grade

-With Optional PTI Grade

-Variety Used in Home Applicances, Electronic Equipments, Automatic Machines,

Communication Equipments.

-Variety of Levers


Parameters:

           Ratingp10.1A 48VDC/125VAC(Glod Plated Optional)
031A/3A 125VAC
Operating FrequencyElectrical10~30cycles/minute
Mechancial120cycles/minute
Contact Resistance(Initiative)100mΩMax(Depends on P/Ns)
Insulation Resistance (at 500VDC)at 500VDC 100MΩ Min
Dielectric StrengthAC600V RMS (50~60Hz)
Storage Temperature-40°C~+85°C
Storage Humidity85%RH Max
Service  LifeElectrical6,000~100,000cycles/Depend on part No.
Mechanical5,000,000/1,000,000cycles(optional)
Unit Net WeightAbout 0.5g(straight PCB type without lever)

Drawing:
Related Product

 G3-G5 rppaste-pic-dp_uuid_xcxn3paste-pic-dp_uuid_gq503

Packaging & Shipping

    2



More about packaging details:

No.

Greetech Product

Inner Box

Shipper Carton

MPQ

Inner box size(mm)

Q'ty/(pcs)

Total GW(kgs)

Carton size(mm)

Q'ty/ctn
(pcs)

Total GW(kgs)

MOQ

(pcs)

L/T

(Days)

Total GW(kgs)

1

G3 series(terminal type)

310x215x135

3,360

3.9

440x325x300

13,440

15.3

1,000

15

1.2

2

G5 series

310x250x120

600

5.5

330x270x270

1,200

10.8

1,000

15

9.0

3

G5W11 series

310x215x135

200

4.8

440x325x300

800

19.2

100

10

2.5

4

G6 series

290x192x40

500

1.3

400x305x220

5,000

12.5

1,000

15

2.7

5

G9 series(terminal type)

290x192x40

500

1.3

400x305x220

5,000

12.5

1,000

15

2.7

6

G91 series

290x192x40

500

1.3

400x305x220

5,000

12.5

1,000

15

2.7

7

G10 series

290x192x40

600

1.3

400x305x220

6,000

12.5

1,000

15

2.7

8

GT02 series

210x155x55

300

1.2

440x325x285

6,000

12.0

6,000

15

12.0

9

GPS100 series

/

/

/

330*270*270

60

6.1

60

10

6.1

10

Switch with wire leads

310x215x135

100

1.8

440x325x300

800

14.5

800

20

14.5



shipping:

shipping way pic





Company Information

 Greetech Advantages:

1. ISO9001 & TS16949 qualified

2. Most products are produced & tested by automatics

3. Automatic machines are designed and assembled by our own team

4. Awarded as National Innovative Technology Company

5. Strong R&D team, authorized over 30 patents

6. UL, cUL, ENEC & CQC Certificated, 100% RoHS & Reach compliance

()2



Certificates





Business partners





Trade Records



Trade Shows and Customer Visiting:

Exhibition and Customer Visiting.jpg



FAQ

 Q1. Are you a trading company or manufacturer?

A:  Yes. We are a manufacturer specializing in switches over 30 years.



Q2. What is your MOQ?

A : Normally, MOQ=100pcs.



Q3. What’s the warranty time?

A:   1 - 2 years.



Q4. Could you offer us free samples?

 A) Yes, free samples could be  provided within  2-5 days.



Q5, What ‘s  the lead time of mass production?

A :  About 2-4 weeks.



Q6. What’s the capacity per month?

A :   Over 8 million pieces per month for micro switch series.

       Over 20 million pieces per month for keyboard switch series,



Q7. Where is your plant?

A:  Located in Huizhou city, Guangdong province, China.

      About 70 minutes by car from Shenzhen airport and about 2 hours from HK airport.



Q8 . Could you accept OEM or ODM ?

A :  Yes, we have a strong R&D team. We have rich experience on OEM&ODM.
